Products
All of FAR's pyrometers are expert-system multi-wavelength instruments. For each and every measurement they examine several hundred distinct pieces of data, any two of which are sufficient to calculate a temperature. All data are analyzed in concert so that decisions on how to proceed use all the information available. Consequently, interference is discarded, noise is suppressed, and emissivity changes are detected and corrected. After the data have been processed, the result is tested for quality and the measure of quality, the tolerance, is displayed. These are the first pyrometers to give the user this crucial information. These instruments replace guesswork with data.
FMP series SpectroPyrometer in harsh service enclosure
| Fiberoptic illuminator: | helium-neon laser (632.8 nm) for aiming pyrometer |
| Fiberoptic multiplexer: | multiplexes up to 9 optical inputs to one pyrometer; pyrometer console provides control |
| Aiming lens holder: | attaches lens assembly to sight tube or vacuum port; units are purged, adjustable on 3 axes, with removable quartz window |
| Data analysis: | spread sheet template for generation of absorption/emission and emissivity charts |
| Custom peripherals: | FAR has provided many unique items to adapt our modular approach to temperature measurement to many challenging applications. We would be happy to do so for your application. |
